C6 · Components · Splitters & couplers
PLC Splitters
Planar lightwave circuit splitters divide one fibre evenly across 2 to 64 outputs, with flat loss across every wavelength used in PON and CATV. Available as micro steel-tube, ABS box, LGX cassette and rack formats.
Features
- Flat loss across the PON and CATV window
- Micro, ABS box, LGX cassette and rack formats
- Even split across all outputs
Applications
- PON / FTTH distribution
- CATV splitting
- Distribution boxes
Specifications are typical unless stated and may change without notice. Patch cords and assemblies are terminated with connectors from leading global manufacturers; Scientific optical transceivers are made in India. Confirm current values with our sales team before ordering.
Common data
- Wavelength
- 1260 – 1650 nm
- Directivity
- ≥ 55 dB
- Operating temperature
- -20 to +80 °C
- Formats
- Steel-tube micro (0.9 mm) · ABS box · LGX cassette · rack
- Connectors
- SC · LC · FC — UPC / APC, or bare
Range
- Product range
- Splitters & couplers
Optical performance by split ratio
| 1×2 | 1×4 | 1×8 | 1×16 | 1×32 | 1×64 | |
|---|---|---|---|---|---|---|
| Max. insertion loss, dB | 3.8 | 7.2 | 10.3 | 13.5 | 16.5 | 20.5 |
| Uniformity, dB | 0.4 | 0.6 | 0.8 | 1.0 | 1.5 | 2.0 |
| PDL, dB | 0.2 | 0.2 | 0.2 | 0.3 | 0.3 | 0.4 |
| Return loss, dB | ≥ 55 | ≥ 55 | ≥ 55 | ≥ 55 | ≥ 55 | ≥ 55 |
1×64
Max split
≤ 20.5 dB
1×64 loss
≥ 55 dB
Return loss
1260–1650
nm window
Related products
C7FBT Splitters & Ratio Couplers
