02 · Indoor & Patch
Simplex & Duplex Indoor Cable
Tight-buffered cable in 2.0 and 3.0 mm for patch cords, pigtails and indoor links. SM G.657A1/A2 and MM OM3/OM4, LSZH or PVC jacket.
Features
- Tight-buffered for easy termination
- Singlemode and multimode
- LSZH for indoor safety
- Patch cords, pigtails and indoor links
Environmental
- Operating
- -20 to +70 °C
- Storage
- -30 to +70 °C
- Installation
- -10 to +70 °C
- Jacket
- LSZH or PVC
- Standards
- IEC 60794, IEC 60793, ITU-T G.657, ISO/IEC 11801
Mechanical
| Simplex 3.0 | Simplex 2.0 | Duplex 3.0 | Duplex 2.0 | |
|---|---|---|---|---|
| Fibre count | 1 | 1 | 2 | 2 |
| Diameter (mm ±5%) | 3.0 | 2.0 | 3.0×6.2 | 2.0×4.2 |
| Weight (kg/km ±10%) | 9 | 4 | 18 | 8 |
| Max tensile (N) | 150 | 100 | 200 | 150 |
| Crush (N/100 mm) | 300 | 200 | 300 | 200 |
| Bend radius dynamic | 20D | 20D | 20D | 20D |
Optical · singlemode (typ / max dB/km)
| 1310 nm | 1550 nm | |
|---|---|---|
| G.657A1 | 0.34 / 0.40 | 0.25 / 0.30 |
| G.657A2 | 0.335 / 0.380 | 0.200 / 0.250 |
Optical · multimode duplex
| 850 nm max | 1300 nm max | BW @850 nm | |
|---|---|---|---|
| OM3 | 3.5 dB/km | 1.5 dB/km | 2000 MHz·km |
| OM4 | 3.5 dB/km | 1.5 dB/km | 4700 MHz·km |
2.0 / 3.0
mm diameters
4
Variants
OM4
Up to 4700 MHz·km
LSZH
Jacket option
