03 · FTTH
FTTH Drop Cable
Single, dual and figure-8 self-supporting drop cable with G.657A2 fibre. Notched profile for fast field access on the last metres to the home.
Features
- Notched profile for fast field access
- G.657A2 bend-insensitive fibre
- Self-supporting figure-8 for aerial spans
- Black or white LSZH
Flat drop
- Fibre count
- 1F / 2F
- Dimensions
- 2.0 × 3.0 mm
- Strength member
- 2× steel wire Ø 0.4 mm or FRP Ø 0.5 mm
- Tensile long / short
- 80 / 40 N
- Crush
- 2200 / 1000 N/100 mm
- Min bend radius static / dynamic
- 15 / 30 mm
- Jacket
- LSZH, black or white
- Operating
- -20 to +60 °C
Figure-8 self-supporting
- Fibre count
- 1F / 2F
- Dimensions
- 2.0 × 5.2 mm
- Messenger
- Steel Ø 1.0 mm
- Tensile
- 600 / 300 N
- Bend radius
- 20 / 40 mm
- Jacket
- LSZH or PE, black
- Operating
- -40 to +70 °C
20 mm
Fibre bend radius
G.657A2
Fibre
1F · 2F
Counts
3
Variants
